Features :

• Latest Micro Controller based design
• Rugged construction
• ADI Artech (USA) Make Heavy Duty Load cell for rough handling
• Stainless Steel Valve with Teflon coating
• Coarse and fine feed for better accuracy
• Auto calibration (thru Key Pad)
• High internal count greater than 2,00,000 counts
• Data retention in memory even power failure Gross/Net filling.
• Top Rollers and side roller conveyor for easy handling of drums
• In-Mouth filling & hence no spillage
• Local control panel for easy Operation.

Specification :

• Fill Accuracy : Better than + / - 0.1% FSR
• Display : 0.5 mm height (7 segments LED)
• Load Sensor : Strain Gauge Based Load sensor
• Fill Mode : Auto/Manual
• No. of Fillings : 1 fillings per minute (Depends on the flow available)
• Fill Valve : SS with Teflon Lining
• Operating Temp : 5-50 degree C
• Operating Pressure : 6-8 bar
• Power Supply : 230v Ac, 50 Hz +/- 10%
• Platform Size (mm) : As per Customer Requirement.

Application :

Edible Oils, Lubricants, Paints, Chemicals & Other Liquids

Options :

Printer interface, Computer interface, Remote Display, Higher Capacity, Flame Proof

Capacity	Resolution
100 Kg	20 gm
200 Kg	50 gm
300 Kg	50 gm
500 Kg	100 gm
